Additional Information
| Weight | 0,1 kg |
|---|---|
| Dimensions | 2 × 18 × 8 cm |
| Connection Type | Connect and Play, Panel Only, Plug and Play |
Price range: 25,00 € through 115,00 € excluding Tax
| Weight | 0,1 kg |
|---|---|
| Dimensions | 2 × 18 × 8 cm |
| Connection Type | Connect and Play, Panel Only, Plug and Play |
Only logged in customers who have purchased this product may leave a review.
Are you a flight enthusiast or a professional looking to enhance your flight simulator with authentic details? The Simbay Bottom Right Side Panel is designed to precisely replicate the Boeing 737 cockpit experience. Crafted from two layers of durable acrylic sheets, this replica panel embodies the fine craftsmanship and realistic appearance that aviation lovers crave, bringing realism right to your simulator setup.
Imagine interacting with a panel painted in Boeing’s signature Iron Gray (RAL 7011), complete with accurately placed annunciators, annunciator boxes, and authentically styled push buttons and rotary knobs. Whether you’re a hobbyist reconstructing a Boeing 737 cockpit or a commercial flight school aiming to provide effective training tools, this panel delivers a tactile and visual fidelity essential for immersive flight simulation.
Beyond just appearance, this Bottom Right Side Panel from Simbay comes fully equipped with functional elements designed for genuine simulation performance. The warm white backlighting isn’t merely aesthetic; it provides clear visibility in dim lighting conditions, simulating the cockpit environment accurately for night flights or training sessions in low light.
Each panel includes:
Flight enthusiasts know that every detail counts when it comes to creating an immersive cockpit. The Simbay panel fulfills the desire for authenticity with a panel size of 190mm x 84.5mm, just like the original Boeing 737 layout. School instructors appreciate the functional integration and realistic feedback this panel provides, supporting high-quality pilot training experiences.
Its Iron Gray RAL7011 finish and warm white backlighting reproduce cockpit conditions for any time of day, strengthening muscle memory and situational awareness during simulation. The inclusion of labeled push and rotary knobs enhances the interface, helping students and hobbyists quickly locate and interact with controls just as they would in an actual aircraft.
This Simbay replica panel includes a well-documented PCB layout with an IDC connector, ensuring compatibility with various flight simulator systems. The separate 12 volts connector for backlighting allows you to power the panel in line with other cockpit electronics without complication. Installation is intuitive, and the provided data sheet guides you effortlessly from start to finish.
Stop compromising with generic or incomplete cockpit panels. The Bottom Right Side Panel transforms your flight simulation cockpit into a faithful Boeing 737 environment, enhancing realism, training quality, and your flying enjoyment. Whether simulating at your home airport setup or in a commercial training environment, this panel delivers trusted performance combined with authentic aesthetics.
Invest in your cockpit’s detail and feel the difference when you reach for the controls, just like a professional pilot. Order your Simbay Bottom Right Side Panel today and experience the satisfaction of real Boeing 737 cockpit functionality and look — all within your flight simulator.
Ready to upgrade? Click to order now and bring authentic Boeing simulation to your cockpit setup!
The panel measures 190mm x 84.5mm, designed to fit faithfully in a Boeing 737 cockpit replica setup.
Yes, this version includes warm white backlighting for both the panel and buttons, powered through a dedicated 12 volts connector.
The panel comes with push buttons and rotary knobs that can be integrated to simulate real cockpit functions, complete with a PCB and IDC connector for wiring.
Absolutely, a detailed data sheet is provided for download, ensuring you can easily wire and install the panel within your simulator setup.
Yes, the Simbay Bottom Right Side Panel is ideal for both flight enthusiasts and commercial flight schools seeking realistic and reliable simulator components.
This set includes the front and back panels, all annunciators, knobs, and switch guards.
Note: No electronic components are included. You will need to purchase switches, toggle switches, rotary switches, encoders, or potentiometers separately.
This is a fully functional unit that must be connected via the IDC connector pins on the back of the PCB to a controller board. Programming is required.
Pin layout information is either printed on the PCB or provided in a separate datasheet.
This version comes pre-programmed and USB-ready for use with your preferred flight simulation software.
Simply plug it in, install the provided configuration files, and you’re ready to fly!
Power Supply Note:
Because the panels can be daisy-chained using their power connectors, single-panel products do not include a 12V power adapter. Only one adapter is required to power your entire custom cockpit setup. The power supply is used solely for the backlighting, not for the product’s core functions.
All knobs are high-quality, resin 3D-printed components with realistic designs. They are supplied with a D-shaft fitting.
For modifications or custom requirements, please contact our support team.
The gauges are powered by SG90 servo motors, compatible with most available controller boards. Each unit includes one or two pre-mounted servo motors.
Calibration must be done via your software or firmware.
Where specified, we use 28BY stepper motors with a ULN2003 driver board.
Electronics are available as complete packages or individual components. When selecting a color or type, you will receive the specified quantity of the chosen product.
PCB Only: Includes just the bare PCB. You can order components separately.
PCB + Electronic Components: Includes a blank PCB plus all necessary components for you to solder.
Soldered PCB: Fully soldered and tested by us. Ready to connect to your controller board and program.
Cet ensemble comprend les panneaux avant et arrière, tous les voyants, boutons et protections de commutateur.
Remarque : aucun composant électronique n’est inclus. Vous devrez acheter séparément les commutateurs, les commutateurs à bascule, les commutateurs rotatifs, les encodeurs ou les potentiomètres.
Il s’agit d’une unité entièrement fonctionnelle qui doit être connectée via les broches du connecteur IDC à l’arrière du circuit imprimé à une carte de contrôleur. Une programmation est nécessaire.
L’agencement des broches est soit imprimé sur le circuit imprimé, soit fourni dans une fiche technique séparée.
Cette version est pré-programmée et prête pour l’USB pour une utilisation avec le logiciel de simulation de vol de votre choix.
Il suffit de le brancher, d’installer les fichiers de configuration fournis et vous êtes prêt à voler !
Remarque sur l’alimentation électrique :
Comme les panneaux peuvent être chaînés en utilisant leurs connecteurs d’alimentation, les produits à panneau unique n’incluent pas d’adaptateur secteur 12V. Un seul adaptateur est nécessaire pour alimenter l’ensemble de votre installation de cockpit personnalisée. L’alimentation électrique est utilisée uniquement pour l’éclairage de fond, pas pour les fonctions de base du produit.
Tous les boutons sont des composants 3D imprimés en résine de haute qualité avec des conceptions réalistes. Ils sont fournis avec un adaptateur en forme de D.
Pour les modifications ou les exigences personnalisées, veuillez contacter notre équipe d’assistance.
Les jauges sont alimentées par des moteurs servo SG90, compatibles avec la plupart des cartes de contrôleur disponibles. Chaque unité comprend un ou deux moteurs servo pré-montés.
L’étalonnage doit être effectué via votre logiciel ou votre firmware.
Lorsque cela est spécifié, nous utilisons des moteurs pas à pas 28BY avec une carte pilote ULN2003.
Les composants électroniques sont disponibles sous forme de paquets complets ou de composants individuels. Lors de la sélection d’une couleur ou d’un type, vous recevrez la quantité spécifiée du produit choisi.
Carte de circuit imprimé seulement : Inclut uniquement la carte de circuit imprimé nue. Vous pouvez commander les composants séparément.
Carte de circuit imprimé + composants électroniques : Inclut une carte de circuit imprimé vierge ainsi que tous les composants nécessaires pour que vous puissiez les souder.
Carte de circuit imprimé soudée : Entièrement soudée et testée par nos soins. Prête à être connectée à votre carte de contrôleur et à être programmée.
