If you’re a flight enthusiast or part of a commercial flight school looking to elevate your Boeing 737 simulation experience, our Lights Test Panel MIP Boeing 737 replica is just what you need. Crafted from a 3mm thick acrylic sheet and painted in authentic Boeing gray RAL 7011 (iron gray), this Aircraft Simulator Panel brings unmatched realism and functionality to your cockpit setup.
This panel features all the key annunciators, annunciator boxes, knobs, and push buttons exactly as found in a real Boeing 737. Every push button switch and rotary knob is meticulously replicated, with options to include labeled and unlabeled controls, making it perfect as a backlit panel that enhances visual clarity with warm white lighting. The panel’s gauge layout aligns precisely with actual cockpit gauge panels, ensuring a seamless experience for training or simulation.
Whether you’re a passionate flight simulation hobbyist or part of a commercial flight school, this Boeing 737 Lights Test Panel replica is designed to boost your cockpit’s authenticity. Its detailed annunciator labels, quality push buttons, and rotary knobs replicate the tactile controls pilots train on every day. The temperature of the backlighting is carefully selected to provide a warm, non-distracting glow that ensures all controls are visible without interfering with the realism of your flight deck lighting conditions.
Worried about installation? The included data sheet for the C&P version details every connector pin function, and the clear IDC connector on the PCB makes integration into your simulator controls straightforward. Feel confident knowing your investment genuinely enhances the interface with precise and durable engineering.
Our Lights Test Panel for the Boeing 737 offers a replica experience appreciated by thousands of flight sim devotees worldwide. Crafted leveraging high-quality acrylic and enhanced with expertly painted finishes, it brings realism and functional accuracy to your setup. The panel’s backlighting and labeled controls ensure ease of use, even during intense flight sessions, and its compact size makes it an ideal addition without overwhelming your cockpit.
Don’t settle for generic simulator panels. Choose a Lights Test Panel that mirrors the actual Boeing 737 MIP, elevates your simulation’s authenticity, and helps unlock your full potential as a pilot or instructor. Whether you’re practicing procedures or leading classroom training, this panel is your trusted cockpit companion.
Order your Lights Test Panel MIP Boeing 737 replica today and bring your flight simulation to life!
The panel is made from a 3mm thick, high-quality acrylic sheet painted in Boeing’s official gray RAL 7011 to match the original cockpit panel’s color.
Yes, it comes with all annunciators, annunciator boxes, push buttons, and rotary knobs required to replicate the real Boeing 737 MIP Lights Test Panel experience.
For the C&P and P&P versions, warm white backlighting is included, with a separate 12-volt connector to power the illumination.
The backside PCB includes an IDC connector with pins assigned to each function; a detailed data sheet accompanies the panel for easy wiring and integration.
The panel measures 31.5mm by 41.5mm, making it perfectly sized for Boeing 737 simulator multi-instrument panels.
This set includes the front and back panels, all annunciators, knobs, and switch guards.
Note: No electronic components are included. You will need to purchase switches, toggle switches, rotary switches, encoders, or potentiometers separately.
This is a fully functional unit that must be connected via the IDC connector pins on the back of the PCB to a controller board. Programming is required.
Pin layout information is either printed on the PCB or provided in a separate datasheet.
This version comes pre-programmed and USB-ready for use with your preferred flight simulation software.
Simply plug it in, install the provided configuration files, and you’re ready to fly!
Power Supply Note:
Because the panels can be daisy-chained using their power connectors, single-panel products do not include a 12V power adapter. Only one adapter is required to power your entire custom cockpit setup. The power supply is used solely for the backlighting, not for the product’s core functions.
All knobs are high-quality, resin 3D-printed components with realistic designs. They are supplied with a D-shaft fitting.
For modifications or custom requirements, please contact our support team.
The gauges are powered by SG90 servo motors, compatible with most available controller boards. Each unit includes one or two pre-mounted servo motors.
Calibration must be done via your software or firmware.
Where specified, we use 28BY stepper motors with a ULN2003 driver board.
Electronics are available as complete packages or individual components. When selecting a color or type, you will receive the specified quantity of the chosen product.
PCB Only: Includes just the bare PCB. You can order components separately.
PCB + Electronic Components: Includes a blank PCB plus all necessary components for you to solder.
Soldered PCB: Fully soldered and tested by us. Ready to connect to your controller board and program.
