General Product informations

Price range: 140,00 € through 210,00 € excluding Tax

Estimated delivery dates: Oct 16, 2025 - Nov 27, 2025

Additional Information

Weight 0,2 kg
Dimensions 7 × 17 × 5 cm
Connection Type

Connect and Play, Panel Only, Plug and Play

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Simbay KT76A ATC Transponder: The Perfect Home Cockpit Replica

Are you a flight enthusiast or part of a commercial flight school eager to elevate your simulation experience? The Simbay KT76A ATC Transponder is designed with you in mind, offering a highly detailed, accurate replica of the Bendix KT76A transponder tailored for home cockpits. This instrument blends realism with functionality, making your simulated flights feel incredibly authentic.

Bring Realistic ATC Communication to Your Flight Simulation

Flight simulation isn’t just about visuals—it’s about the interactive experience. This home cockpit instrument delivers precisely that. With its matte black panel finish, the unit looks exactly like what you would find in a real cockpit, avoiding distracting glare while maintaining a sleek appearance. The warm white backlighting on the panel and buttons provides comfortable visibility during night flying sessions without straining your eyes.

Key Features That Enhance Your Simulation Experience

  • Red 7 Segment Display: The crisp red numerals on the display are easy to read in all lighting conditions, offering clear, pilot-ready data at a glance.
  • Non-Click Potentiometer: The finely tuned potentiometer allows smooth adjustments without the ‘off’ click, ensuring precise and uninterrupted tuning during your flight simulation.
  • IDC Connector with Detailed Data Sheet: The backside of the PCB features an IDC connector for simple integration, with each pin meticulously assigned to specific panel functions. Plus, you get a detailed data sheet that’s downloadable for easy reference during setup.
  • Compact Panel Size: Measuring 165mm x 43mm, it’s perfectly sized for modern home cockpit layouts, fitting seamlessly into your flight simulation setup.
  • Voltage and Backlight Control: The separate connector for 12V backlight control gives you flexible options to manage your cockpit’s lighting ambiance.

Why Choose This Model for Your Flight Cockpit?

Not all transponders are created equal, especially when it comes to simulation. The Simbay KT76A stands out due to its authentic design, electronic model precision, and user-friendly features. It’s crafted specifically to replicate the Bendix KT76A, a staple in aviation history, making it a trusted choice for pilots wanting to train or enjoy simulation under realistic conditions. The combination of tactile controls, visual fidelity, and easy installation guarantees a satisfying experience.

Overcoming Potential Doubts

Some might worry about compatibility or complexity. Rest assured, the IDC connector and accompanying detailed data sheet make installation straightforward—even for those new to home cockpit building. The non-click potentiometer avoids accidental shutdown, ensuring smooth operation. Plus, with its durable electronic model, the instrument is ready to handle rigorous simulated flight hours without fail.

Make Your Flight Simulation More Authentic Today

Whether you’re training aspiring commercial pilots or a passionate flight enthusiast, this Simbay KT76A ATC Transponder brings a new level of realism and functionality to your flight panel. Embrace the detailed craftsmanship, accurate display, and pilot-focused design to boost your simulated flight’s immersion. Download the detailed data sheet to get started on installing this must-have instrument in your cockpit setup. Don’t just simulate flight—experience it!

Order your Simbay KT76A ATC Transponder now and transform your home cockpit into a professional flight simulation hub.

Frequently Asked Questions

Q1: Is this transponder compatible with all home cockpit systems?

A1: The Simbay KT76A features a standard IDC connector with a detailed data sheet, ensuring compatibility with most home cockpit simulation setups.

Q2: What kind of backlighting does the panel use?

A2: It uses warm white backlighting on the panel and buttons, with a separate 12V connector for customizable lighting control during flight simulation.

Q3: Does the potentiometer have an ‘off’ position click?

A3: No, the potentiometer is designed without a clicking ‘off’ position for smooth adjustment without sudden interruptions.

Q4: Can I download the data sheet for installation guidance?

A4: Yes, the detailed data sheet for panel connections and functions is available for download to assist with setup.

Q5: What are the panel dimensions?

A5: The panel measures 165mm x 43mm, fitting neatly into most home cockpit configurations.

Related Products

Panel Only

This set includes the front and back panels, all annunciators, knobs, and switch guards.
Note: No electronic components are included. You will need to purchase switches, toggle switches, rotary switches, encoders, or potentiometers separately.

Connect and Play

This is a fully functional unit that must be connected via the IDC connector pins on the back of the PCB to a controller board. Programming is required.
Pin layout information is either printed on the PCB or provided in a separate datasheet.

Plug and Play

This version comes pre-programmed and USB-ready for use with your preferred flight simulation software.
Simply plug it in, install the provided configuration files, and you’re ready to fly!

Power Supply Note:
Because the panels can be daisy-chained using their power connectors, single-panel products do not include a 12V power adapter. Only one adapter is required to power your entire custom cockpit setup. The power supply is used solely for the backlighting, not for the product’s core functions.

Knobs

All knobs are high-quality, resin 3D-printed components with realistic designs. They are supplied with a D-shaft fitting.
For modifications or custom requirements, please contact our support team.

Gauges

The gauges are powered by SG90 servo motors, compatible with most available controller boards. Each unit includes one or two pre-mounted servo motors.

Calibration must be done via your software or firmware.

Where specified, we use 28BY stepper motors with a ULN2003 driver board.

Electronics

Electronics are available as complete packages or individual components. When selecting a color or type, you will receive the specified quantity of the chosen product.

PCBs

PCB Only: Includes just the bare PCB. You can order components separately.

PCB + Electronic Components: Includes a blank PCB plus all necessary components for you to solder.

Soldered PCB: Fully soldered and tested by us. Ready to connect to your controller board and program.
