Price range: 70,00 € through 150,00 € excluding Tax
| Weight | 0,2 kg |
|---|---|
| Dimensions | 5 × 5 × 8 cm |
| Connection Type | Connect and Play, Panel Only, Plug and Play |
Only logged in customers who have purchased this product may leave a review.
Step into the world of aviation with the Center Gauges/YAW Damper MIP Panel Boeing 737, a meticulously crafted Boeing 737 Panel designed for flight enthusiasts and commercial flight schools alike. This Boeing 737 Replica features two sturdy acrylic sheets, with a 5mm thickness for the lower layer and a 3mm thick upper front layer, ensuring durability and a realistic feel that mirrors the authentic aircraft instrument panel.
Painted in Boeing’s signature gray, RAL 7011 (iron gray), this 737 MIP Panel captures the authentic look of the Boeing 737 front panel, making it an ideal centerpiece in any training environment or flight simulation setup. The panel includes every essential element — from annunciators and annunciator boxes to various knobs and buttons that function as push and rotary controls. These components add a tactile and functional experience to the replica, perfect for those seeking an immersive aviation feel.
Why settle for ordinary when you can have an Aircraft Panel Replica that combines precision, style, and functionality? The addition of servo-driven, warm white backlit yaw damper gauge in the C&P and P&P versions offers enhanced realism, simulating true aircraft conditions. The carefully engineered panel size (103mm x 351mm) makes this Boeing 737 Components piece suitable for desktop cockpits or educational setups without overwhelming your workspace.
This Acrylic Airplane Panel is expertly painted and designed to match the Boeing Gray Panel standard, making it a coveted choice among aviation aficionados and commercial flight schools looking for accurate and durable aviation gauge panels. Its backlit design enhances visibility even in low light conditions, replicating the exact ambiance of aircraft instrument lighting.
Stop dreaming about flying and start experiencing it with this Boeing 737 MIP Replica that brings every detail right to your fingertips. Whether you’re a commercial flight school aiming to provide students with realistic training or a flight enthusiast looking to enhance your home cockpit, this Boeing 737 Panel delivers precision and authenticity in one sleek package.
Some might wonder why an acrylic replica without a PCB is the right choice. The answer lies in its flexibility and customization potential. Since the panel comes with no PCB, you have the freedom to integrate it with any existing hardware or software system without compatibility hassles. This degree of freedom ensures your flight training or simulation setup stays tailored exactly to your needs.
Moreover, the inclusion of all annunciators and controls means you’re not just buying a static panel — you’re getting a fully interactive flight experience. The use of quality materials and authentic Boeing color coding also means your setup won’t just work well, but will look stunning too, boosting your confidence and enthusiasm every time you use it.
Don’t miss out on owning a piece of aviation craftsmanship that doubles as a perfect training tool and a conversation starter. Designed with expert precision and quality, this 737 MIP Panel is ready to boost your flight skills and inspire your passion. Add it to your cockpit collection or training suite now and feel the difference it makes in your simulation experience.
Order your Center Gauges/YAW Damper MIP Panel Boeing 737 replica today and experience aviation like never before!
This set includes the front and back panels, all annunciators, knobs, and switch guards.
Note: No electronic components are included. You will need to purchase switches, toggle switches, rotary switches, encoders, or potentiometers separately.
This is a fully functional unit that must be connected via the IDC connector pins on the back of the PCB to a controller board. Programming is required.
Pin layout information is either printed on the PCB or provided in a separate datasheet.
This version comes pre-programmed and USB-ready for use with your preferred flight simulation software.
Simply plug it in, install the provided configuration files, and you’re ready to fly!
Power Supply Note:
Because the panels can be daisy-chained using their power connectors, single-panel products do not include a 12V power adapter. Only one adapter is required to power your entire custom cockpit setup. The power supply is used solely for the backlighting, not for the product’s core functions.
All knobs are high-quality, resin 3D-printed components with realistic designs. They are supplied with a D-shaft fitting.
For modifications or custom requirements, please contact our support team.
The gauges are powered by SG90 servo motors, compatible with most available controller boards. Each unit includes one or two pre-mounted servo motors.
Calibration must be done via your software or firmware.
Where specified, we use 28BY stepper motors with a ULN2003 driver board.
Electronics are available as complete packages or individual components. When selecting a color or type, you will receive the specified quantity of the chosen product.
PCB Only: Includes just the bare PCB. You can order components separately.
PCB + Electronic Components: Includes a blank PCB plus all necessary components for you to solder.
Soldered PCB: Fully soldered and tested by us. Ready to connect to your controller board and program.
Cet ensemble comprend les panneaux avant et arrière, tous les voyants, boutons et protections de commutateur.
Remarque : aucun composant électronique n’est inclus. Vous devrez acheter séparément les commutateurs, les commutateurs à bascule, les commutateurs rotatifs, les encodeurs ou les potentiomètres.
Il s’agit d’une unité entièrement fonctionnelle qui doit être connectée via les broches du connecteur IDC à l’arrière du circuit imprimé à une carte de contrôleur. Une programmation est nécessaire.
L’agencement des broches est soit imprimé sur le circuit imprimé, soit fourni dans une fiche technique séparée.
Cette version est pré-programmée et prête pour l’USB pour une utilisation avec le logiciel de simulation de vol de votre choix.
Il suffit de le brancher, d’installer les fichiers de configuration fournis et vous êtes prêt à voler !
Remarque sur l’alimentation électrique :
Comme les panneaux peuvent être chaînés en utilisant leurs connecteurs d’alimentation, les produits à panneau unique n’incluent pas d’adaptateur secteur 12V. Un seul adaptateur est nécessaire pour alimenter l’ensemble de votre installation de cockpit personnalisée. L’alimentation électrique est utilisée uniquement pour l’éclairage de fond, pas pour les fonctions de base du produit.
Tous les boutons sont des composants 3D imprimés en résine de haute qualité avec des conceptions réalistes. Ils sont fournis avec un adaptateur en forme de D.
Pour les modifications ou les exigences personnalisées, veuillez contacter notre équipe d’assistance.
Les jauges sont alimentées par des moteurs servo SG90, compatibles avec la plupart des cartes de contrôleur disponibles. Chaque unité comprend un ou deux moteurs servo pré-montés.
L’étalonnage doit être effectué via votre logiciel ou votre firmware.
Lorsque cela est spécifié, nous utilisons des moteurs pas à pas 28BY avec une carte pilote ULN2003.
Les composants électroniques sont disponibles sous forme de paquets complets ou de composants individuels. Lors de la sélection d’une couleur ou d’un type, vous recevrez la quantité spécifiée du produit choisi.
Carte de circuit imprimé seulement : Inclut uniquement la carte de circuit imprimé nue. Vous pouvez commander les composants séparément.
Carte de circuit imprimé + composants électroniques : Inclut une carte de circuit imprimé vierge ainsi que tous les composants nécessaires pour que vous puissiez les souder.
Carte de circuit imprimé soudée : Entièrement soudée et testée par nos soins. Prête à être connectée à votre carte de contrôleur et à être programmée.
